Installation & Application（安装应用） Product Dimension Drawing
Technical Parameters（技术参数） | Category | Specification |
|---|---|
| Output | 9× 10A universal socket outlets |
| Input | Left-side 3-core cable entry |
| Protection/Monitoring | No surge protection |
| Maximum Total Load | 16A |
| Rated Voltage | AC 220V |
| Enclosure Color | Black |
| Mounting Type | Bottom-side fixation |
| Mounting Dimensions | 459mm×32mm (four Φ6mm holes) |
| Overall Dimensions | 485mm×44.5mm×44.5mm |
Ordering and Model Selection（订货选型） *Please send the inquiry email containing specific product requirements (such as model, quantity, technical parameters, etc.) to the designated email address salina@kejia.com.
（请将包含具体产品需求（如型号、数量、技术参数等）的询价邮件发送至指定邮箱 salina@kejia.com）
