Installation & Application（安装应用） Surge-protected PDU grounding terminal (PE) must be securely connected to the equipment room or building's equipotential grounding busbar. When the green "ON LINE" indicator light on the surge protector turns off, it indicates the surge protector has failed and can no longer provide lightning/surge protection. It is recommended to replace the entire unit or the internal surge protection module。
Product Dimension Drawing
Technical Parameters（技术参数） | Model | NKP-DY-IIIU-16A | NKP-DY-IIIU-32A |
|---|---|---|
| Applicable Power | AC220V (inside cabinet) | AC220V (inside cabinet) |
| Power System | 2-wire AC | 2-wire AC |
| Nominal Working Voltage (Un) | AC220V | AC220V |
| Maximum Continuous Operating Voltage (Uc) | AC275V | AC275V |
| Rated Operating Current | 16A | 32A |
| Nominal Discharge Current In (8/20µs) | 5kA | 5kA |
| Maximum Discharge Current Imax (8/20µs) | 10kA | 10kA |
| Voltage Protection Level (Up) | <1200V | <1200V |
| Enclosure | 1U standard chassis size, fixed inside cabinet | |
| Material | Aluminum alloy (black) | |
| Mounting Type | Bottom-side fixation | |
| Mounting Dimensions | 459mm×32mm (four Φ6mm holes) | |
| Overall Dimensions | 485mm×44.5mm×44.5mm | |
Ordering and Model Selection（订货选型） *Please send the inquiry email containing specific product requirements (such as model, quantity, technical parameters, etc.) to the designated email address salina@kejia.com.
